Ducted HVAC
Smart Thermostat
Universal Climate Controller for Commercial and Residential HVAC Infrastructure
The IA-HVAC Smart Climate Controller delivers unified automation across ducted, split-system, VRV/VRF, and hydronic HVAC equipment through a... Read more
Ducted HVAC
Smart Thermostat
Universal Climate Controller for Commercial and Residential HVAC Infrastructure
The IA-HVAC Smart Climate Controller delivers unified automation across ducted, split-system, VRV/VRF, and hydronic HVAC equipment through a... Read more
Professional HVAC Applications.
Smart Climate management for ducted heating and cooling
Accelerated Retrofit Economics
Operational Cost Reduction Through Precision Control
Proactive Maintenance and Remote Diagnostics
Accessibility Compliance and Future-Proof Architecture
Strategic Value Proposition Why Mechanical Contractors and Property Developers Specify IA-HVAC Unified Platform for Mixed-Manufacturer Portfolios
Retrofit HVAC systems with app and voice control.
Retrofit HVAC systems with app and voice control.
Advanced Feature Architecture
Universal HVAC Compatibility Matrix
Ten pre-configured relay operating modes support conventional 24V control boards across si... Read more
Contractor-Optimized Installation Design
Color-coded wire harnesses with molded A-D terminal blocks eliminate field labeling and wi... Read more
Architectural Wall Sensor Design
The minimalist two-wire sensor replaces bulky programmable thermostats with a single tacti... Read more
Voice Assistant Integration
Enable hands-free temperature adjustment through Amazon Alexa and Google Home ecosystems. ... Read more
Enterprise-Grade Security and Access Control
WPA2-encrypted Wi-Fi connectivity and AES-encrypted firmware updates protect against unaut... Read more
Comprehensive System Monitoring
Access real-time runtime data, historical temperature logs, and equipment cycle counts thr... Read more
Smooth Immersive Experience.
Technical Specifications
| Parameter | Specification | Engineering Notes |
|---|---|---|
| Input Power | 12-24 VAC/DC, 1W typical consumption | Extra-low-voltage design eliminates electrical licensing requirements in most jurisdictions |
| Relay Outputs | 4 * SPST, 2A @ 30VDC/VAC resistive load | Suitable for standard 24V HVAC control circuits including fan, heating, cooling, and reversing valve |
| Serial Interface | RS-485 (Modbus RTU), isolated | Accepts manufacturer-specific protocol adaptors for major inverter system brands |
| Network Protocol | IEEE 802.11 b/g/n (2.4 GHz Wi-Fi) | Direct router connection eliminates proprietary hubs and recurring subscription costs |
| Operating Environment | -10°C to +50°C, 0-90% RH non-condensing | Rated for installation in mechanical rooms and rooftop equipment enclosures |
| Physical Dimensions | 89mm * 70mm * 26mm, IP20 enclosure | Compact profile fits inside air handler cabinets and service panels |
| Quality Assurance | 3-year return-to-base warranty | Australian-based support and spare parts inventory |
| Regulatory Compliance | AS/NZS 60335 & 3000 design standards | Engineered for Australian electrical safety requirements |
Our Clients.
Ready to Make Your Home Smarter?
We design, install, and support everything you need to live smarter and safer.
Infinite Automation is an automation solutions company based in Melbourne, Australia. Our products are proudly Australian made.
